ELNUR CMX DIGITAL MODULATING BOILERS:

The entire range of Elnur Electric Boilers can be used with hot water radiators or with radiant under floor heating, with room or programmable thermostats, and unlike other boilers, they do not require yearly maintenance or safety inspections. They are the ideal option in both 3 x 400V+N ~AC and 230V ~AC. The boiler is compatible for single or three phases by using the bridge connection(included) in the terminal block. Installations do not require venting or gas outlets which may compromise the insulation of your home.

Elnur electronic boilers are completely silent thanks to their TRIAC-based technology. Moreover, they have a modulating operation which, combined with a good exterior programmable thermostat (see accessories), adapts the heating power to the needs of the system, achieving maximum energy efficiency and a considerable saving in consumption.

The maximum power can be limited to any of the modulation levels. On the CMX15 this range is from 15Kw down to 2Kw.

The digital display constantly shows the temperature of the circulating heating water and of the Domestic Hot Water (DHW) tank. Adjustment of the heating and DHW is made easier by using individual keys to increase or decrease the temperature. You can disconnect the heating system in summer and both keypads can be locked to prevent changes. The electronic control of the circulation pump prevents blockage during long periods of inactivity.

Available in 15Kw.

Heating boiler made of insulated steel.

50L DHW cylinder made of insulated stainless steel without CFC's.

Stainless steel shielded elements INCOLOY800 for HEATING and DHW.

6L heating expansion vessel.

2L DHW expansion vessel.

Modulating electronic control of the heating elements.

DHW electronic regulation.

Digital display

Hydrometer 0-4bar

Circulating pump

Can be installed as single or 3-phase

Auto air vent.

Silent TRIAC power switches.

Heating flow detector.

Heating temperature limiter 100°C.

DHW temperature limiter 80°C.

Heating pressure relief valve 3 kg/cm2.

DHW pressure relief valve 7 kg/cm2.

Room thermostat inlet.

Optional under floor heating kit.

Powder coated RAL 9010.
